MPB25 Series
25mm Metal Switches
Dailywell MPB25 series illuminated anti-vandal switches is UL certified, offering a rating of 3A/250VAC; 3A/28VDC. The distinctive features are IP67 rated and long operating life of up to 1,000,000 life cycles (momentary) and 500,000 (latching).
We offer multiple color ring illumination options, and multiple voltage options. It comes with a 25mm panel cutout size and SPDT or DPDT function.
MPB25 Series
25mm Metal Switches
Dailywell MPB25 series illuminated anti-vandal switches is UL certified, offering a rating of 3A/250VAC; 3A/28VDC. The distinctive features are IP67 rated and long operating life of up to 1,000,000 life cycles (momentary) and 500,000 (latching).
We offer multiple color ring illumination options, and multiple voltage options. It comes with a 25mm panel cutout size and SPDT or DPDT function.
| Specifications | Rating | Electrical life | Mechanical life | Insulation resistance | Dielectric strength | Contact resistance | Travel | Operation pressure | Torque |
|---|---|---|---|---|---|---|---|---|---|
| MPB25 | Ith 5A/250VAC. resistive load 3A/250VAC | 50,000 make-and-break cycles at full load. | Momentary 1,000,000. / Self-lock 500,000 | 1,000MΩ MIN AT 500VDC | 2,000V sea level 2,000V sea level | 50mΩ MAX.@1A 12VDC (initial value) | About 3.2mm. | 1Pole 1.5 ~ 2.5N. / 2Pole 2.2 ~ 3.5N | 5 ~ 14Nm |
‧Metal Switch Series – Quick Terminal Connector
Be designed it more flexible for users wiring requirements, Dailywell provides quick-connect terminal connector for your option.
Metal dimension available for 19mm, 22mm, 25mm.
